NLT4MP-BAG
neutrik-fr / Produits / NLT4MP-BAG

NLT4MP-BAG

Download Data Sheet

4 pole male chassis connector, black-chrome metal housing, solder or ¼" flat tabs

The speakON STX Series was especially designed for heavy duty amplifier-loudspeaker applications like professional touring. The extremely rugged and durable STX Series features an all metal housing.

Features & Benefits
  • Extremely robust metal housing designed for harsh and demanding environment
  • Ideal product for touring applications and harsh environments
  • Current rating 40 Amp continuous, 50 Amp audio with 50% duty cycle
  • Uses precise “Quick Lock” system
  • Mates with all currently available speakON products
  • Weatherproof built-in gasket meets IP 54 protection class in mated condition
  • 4 pole version has UL Recognized components, CSA listed
  • 4 type range - also male cable connector and female receptacle on 4-pole version
Downloads
nlt4mp-1
stp - 104.07 KB
nlt4mp-2
pdf - 56.46 KB
nlt4mp-3
dxf - 322.9 KB
03 Section speakON PG EN 202202-V23
pdf - 5.55 MB
speakon-wiring-suggestion
pdf - 342.87 KB
speakon-flange-and-fastening-layout
pdf - 130.14 KB

Technical Information

Product
Title NLT4MP-BAG
Connection Type speakON
Gender male
Electrical
Contact resistance < 2 mΩ (after lifetime)
Dielectric strength 4 kVdc (peak)
Insulation resistance > 10 GΩ
Rated current per contact 40 A rms continuous
Rated current per contact 50 A audiosignal, duty cycle 50 %
Rated voltage 250 V ac
Attention speakON is NOT to be used as an AC mains or power supply connector!
Mechanical
Lifetime > 5000 mating cycles
Wiresize
Locking device Quick Lock
Chassis shape square G-size flange
Layout four thru holes
Material
Contact plating 4 µm Ag
Insert Polyamide (PA 6 30 % GR)
Shell Zinc diecast (ZnAl4Cu1) black chrome
Contacts Spring Copper (CuSn0.2)
Environmental
Flammability UL 94 HB
Protection class IP 54 (mated condition)
Solderability Complies with IEC 68-2-20
Temperature range -30 °C to +80 °C
Accessories
CAS-DUMMY

The dummyPLUG case includes a mixed assortment of dummyPLUGs

audio
NDL

The dummyPLUG NDL for all 4 pole Neutrik speakON and powerCON chassis enables you to simplify cabling.

audio
SCL

Dust protection cover for most speakON and powerCON chassis connectors

audio
SCNLT

Gasket for speakON G-size housings for an airtight connection between chassis and frontpanel (also suitable for Amphenol EP cutouts)
